HSD ES915A High Speed Spindle Motor

$3,750.00

This motor is from a Biesse Stream Edgebander and has about 40 hours of run time. Terrific condition.

1 in stock

Description

HSD ES915A 4-pole automatic tool change, 30 taper, 8 hp high speed spindle motor. This motor is from a Biesse Stream Edgebander and has about 40 hours of run time and is in immaculate condition. 30 taper, air cooled, ATC, 4 pole, to 240000 rpm.

Special Motor Construction: Spindle Motor
Shaft Diameter: 30 Taper
Shaft Type: 30 taper ATC
Actual Rated Input Voltage: 380
NEMA Frame Suffix: Face Mount
AC Frequency Rating: 400 hz
Brand: HSD
Country/Region of Manufacture: Italy
Model: ES 919A
DC Stator/Winding Type: Permanent Magnet
AC Phase: Three Phase
Protection Against Solids: Dust Protected
Reversible/Non-Reversible: Reversible
Service Factor: –
AC Motor Type: Induction/Asynchronous
IP Rating: 64
Base RPM: 12000
Nominal Rated Input Voltage: 380 V
Current Type: AC
Protection Against Liquids: Not Protected
Mounting Type: Face-Mounted
Enclosure Type: Air Purged Dust Protected
Full Load Amps: 12
Rated Load (HP): 8 @ 12000 rpm
IEC Frame Size: HSD Standard
Inverter/Vector Duty Rating: Inverter Duty
Insulation Class: F (Max 311°F)
MPN: H6161H0309
