Giordano Colombo High Speed Spindle Motor

$2,000.00

Part is used but in great shape. Please contact us for more information.

1 in stock

Description

Giordano Colombo RV110.22 High Speed Spindle Motor 9HP 15.6 A IP54 12000-24000. Part is used but in great shape. Please contact us for more information. This is a very very clean motor!! Giordano Colombo RV110.22 High Speed Spindle Motor 9HP 15.6 A IP54 12000-24000. This is a 30 taper gear tooth/gear teeth style no slip tool holder as used by SCM and Morbidelli CNC machines.

Rated Load (HP): 9 Hp
Reversible/Non-Reversible: Reversible
IP Rating: IP54
Definite Purpose Motor Type: CNC Spindle Motor
Brand: Giordano Colombo
Current Type: AC
Model: ATC Gear Tooth Style SCM
Nominal Rated Input Voltage: 380 V
AC Phase: Three Phase
Mounting Type: Face-Mounted
Shaft Type: 30 Taper
Full Load Amps: 15.6
Country/Region of Manufacture: Italy
MPN: Type 110.22
AC Frequency Rating: To 400 HZ
